The face recognion devices are powered via 12 VDC power output interface of the main and
sub lane control board.
●
Barrier open at the entrance: connect to BTN1 and GND.
●
Barrier open at the exit: connect to BTN2 and GND.
4.4 Device Sengs via Buon
You can congure the device via buon on the lane control board.
Note
●
Refer to Buon Conguraon Descripon for detailed informaon.
●
If the oponal board is not installed, the error code of "59" will appear but the device funcons
normally.
●
For the main lane, "99" is displayed on the screen by default. For the sub lane, "00" is displayed
on the screen by default.
4.4.1 Conguraon via Buon
Buon Descripon
Figure 4-13 Buon
Exit Buon
DS-K3BC430LX Series Swing Gate
19
