Import
Click and select the le to import. Click Import to start import conguraon le.
7.5.14 Device Debugging
You can set device debugging parameters.
Steps
1.
Click Maintenance and Security → Maintenance → Device Debugging .
2.
You can set the following parameters.
Enable SSH
To raise network security, disable SSH service. The
conguraon is only used to debug the
device for the professionals.
Print Log
You can click Export to export log.
Capture Network Packet
You can set the Capture Packet Duraon, Capture Packet Size, and click Start to capture.
7.5.15 Overview
You can view the main lane and sub lane status.
Main Lane Status
Device Component
You can view the status of the access control board, lane control board and user extended
interface board.
Peripheral
You can view the status of the RS-485 card reader and RS-232 card receiver.
Temperature
You can view the pedestal temperature.
Movement
You can view the working status of motor encoder.
Sub Lane Status
Device Component
You can view the status of the lane control board.
Peripheral
DS-K3BC430LX Series Swing Gate
49
