HIKVISION DS-K3BC430LX-868 - 4.3.9 Exit Button Wiring; 4.4 Device Settings via Button; 4.4.1 Configuration via Button

Figure 4-10 Remaining Open
Figure 4-11 Remaining Closed
4.3.9 Exit Buon Wiring
The main and sub lane control board each has 1 buon interface,
which can be connected to exit
buon or face recognion device.
Figure 4-12 Exit Buon Wiring
Note
●
The face recognion devices are powered via 12 VDC power
output interface of the main and sub lane control board.
●
Barrier open at the entrance: connect to BTN1 and GND.
●
Barrier open at the exit: connect to BTN2 and GND.
4.4 Device Sengs via Buon
You can congure the device via buon on the lane control board.
Note
●
Refer to Buon Conguraon Descripon for detailed
informaon.
●
If the oponal board is not installed, the error code of "59" will
appear but the device funcons normally.
●
For the main lane, "99" is displayed on the screen by default.
For the sub lane, "00" is displayed on the screen by default.
4.4.1 Conguraon via Buon
Buon Descripon
