HIKVISION DS-K3G501X Series - Main Optional Board Terminal Description; Sub Optional Board Terminal Description

Note
RS-232A corresponds to UART 1 on web.
4.4.3 Main Oponal Board Terminal Descripon
The main oponal board contains the sub-1G antenna interface, loudspeaker interface, debugging
port, Wiegand/exit buon interface, 5 VDC output and communicaon interface.
Figure 4-4 Main Oponal Board Terminal
4.4.4 Sub
Oponal Board Terminal Descripon
Figure 4-5 Sub Oponal Board Terminal
DS-K3G501X Series Tripod Turnsle
14
