HIKVISION DS-K3G501X Series - Device Settings Via Button; Configuration Via Button

Note
●
The face recognion devices are powered via 12 VDC power output interface of the main and
sub lane control board.
●
Barrier open at the entrance: connect to BTN1 and GND.
●
Barrier open at the exit: connect to BTN2 and GND.
4.5 Device Sengs via Buon
You can congure the device via buon on the lane control board.
4.5.1
Conguraon via Buon
Buon Descripon
The buons are on the lane control board.
Figure 4-12 Buon
Exit Buon
●
Single press to open the gate from the entrance posion.
●
Double press to open the gate from the exit posion.
Parameter Conguraon Buon
●
LEFT: Press to add ten to conguraon data
●
RIGHT: Press to add one
conguraon data
●
CANCEL: Return to the level-1 menu, or exit the conguraon from the level-1 menu
●
OK: Conrm the data, or enter conguraon mode, or enter the submenu
