Page #15 background imageLoading...
Page #15 background image
Chapter 2 System Wiring
The preparaon before installaon and general wiring.
Steps
1.
Draw a central line on the
installaon surface of the le or right pedestal.
2.
Draw other parallel lines for installing the other pedestals.
Note
The distance between the nearest two line is 782 mm.
3.
Slot on the installaon surface and dig installaon holes according to the hole posion. Put 4
expansion bolts for each pedestal.
4.
Bury cables. Each lane buries 1 high and 1 low voltage cable. For details, see the system wiring
diagram below.
DS-K3G501X Series Tripod Turnsle
3
