Note
RS-485B corresponds to port 6 on web and is for QR code scanner connecon by default.
RS-485D corresponds to port 4 on web and is for card reader connecon by default.
RS-232B corresponds to port 2 on web and is for ngerprint reader connecon by default.
4.4.5 Card Reader Board Terminal Descripon
The card reader board can be connected to the access control board via RS-485 interface.
Figure 4-6 Card Reader Board
4.4.6 RS-485 Wiring
The RS-485 interfaces on the access control board and sub oponal board are suggested to
connect with the face
recognion module or the card reader. Here takes connecng with a card
reader as an example.
Note
If there are other RS-485 devices connecng, the ID of the RS-485 cannot be conicted.
The connected 12 V power interface for the face recognion terminal cannot be connected with
other 12 V devices.
DS-K3G501X Series Tripod Turnsle
15
