Name Terminal Descripon
NO1 Door Lock Relay Output 1(Normally Open)
GND Grounding
NC2 Door Lock Relay Output 2(Normally Close)
COM2 Common Interface 2
NO2 Door Lock Relay Output 2(Normally Open)
GND Grounding
Power Supply DC 12 V 12 VDC Power Input
Note
●
Alarm input interface cannot be edited. Refers to the actual model.
●
You can only wire the SEN1/SEN2 terminal with the door contact. And wire the BTN1/BTN2
terminal with the exit buon.
3.2 Wiring Descripon
3.2.1 Door Lock Wiring
Figure 3-2 Door Lock Wiring
Video Intercom Face Recognion Door Staon User Manual
7
