HIKVISION DS-KD9203 Series User Manual

4.2 Flush Mounng with Gang Box
Steps
1.
Cave an installaon hole in the wall. Pull the cable out from the wall.
Note
●
The suggested dimension of the installaon hole is 364.3 mm (W) × 118.6 mm (H) × 40.2 mm
(D).
●
The suggested length of the cables le outside is 250 mm.
2.
Install the gang box into the wall.
1) Remove the plasc sheet of the gang box with the tool.
2) Insert the gang box into the installaon hole. Mark the gang box screw holes' posion with a
marker, and take out the gang box.
3) Drill 4 holes according to the marks on the wall, and insert the expansion sleeves into the
screw holes.
4) Fix the gang box with 4 expansion bolts.
3.
Fix the gap between the gang box and wall with concrete. Remove the
mounng ears with tool
aer concrete is dry. Connect the cables according to the Wiring Descripon.
4.
Insert the door
staon into the gang box. Slide the door staon down and x it with 2 set
screws. Apply Silicone sealant among the joints between the device and the wall (except the
lower side) to keep the raindrop from entering.
Video Intercom Face Recognion Door Staon User Manual
12
