HIKVISION DS-KM8301 User Manual

Video Intercom Master Station·User Manual
3
1.2 Typical Application
PC Client
Center Master
Station
Network
Camera
Master Station
(Guarding Room)
Outer Door Station
Card Reader
Card Reader
Indoor
Extension1
Indoor
Extension2
Elevator Controller
LAN
1F
2F
22F
Resident 1Resident 2
Resident 1Resident 2
Resident 1Resident 2
A Building
Door Station
v
v
v
v
v
v
v
v
Figure 1-2 Typical Application of Master Station
1.3 Terminals and Interfaces
Please refer to the following figure for terminals and interfaces of master station.
Figure 1-3 Real Panel
Table 1-2 Descriptions of Terminals and Interfaces

HIKVISION DS-KM8301 Specifications

General

Brand	HIKVISION
Model	DS-KM8301
Category	Intercom System
Language	English
