HIKVISION DS-KM8301 User Manual

Video Intercom Master Station·User Manual
25
Figure 4-5 Online Devices Interface
2. Click the button to pop up the login dialog box.
Figure 4-6 Login Dialog Box
3. Enter the user name and password.
4. Click the OK button to save the settings.
 Only devices successfully logged in will be added to the device list for configuration.
 If you add devices in batch, please make sure selected devices have the same user
name and password.
4.3.2 Adding by IP Address
Purpose:
You can add the device by entering IP address.
Steps:
1. Click the button to pop up the adding devices dialog box.
Figure 4-7 Adding Button
2. Select IP Address in the adding mode drop-down list.
3. Enter the IP address, and set the port No., user name and password of the device.

HIKVISION DS-KM8301 Specifications

General

Brand	HIKVISION
Model	DS-KM8301
Category	Intercom System
Language	English
