AppendixⅠ Specifications
No.
Name
Description
1
GNSS
GNSS antenna interface
WIFI
Wi-Fi antenna interface. (only supported by the “/GW” devices)
M-ANT
3G antenna interface
2
IR
IR: IR receiver
Receive IR signal from remote control.
3
Indicators
PWR: Power indicator
Turns green after device starts up; Turns red when device stands by.
RDY: Ready indicator
Turns green when the device starts up
REC: Record indicator
Turns green when recording; The light is out when all recording processes are
abnormal.
GNSS: GNSS indicator
No light when GNSS module is abnormal; Turns green when the GNSS module
works normally; Blinks in green after the positioning successful.
ANT: 3G indicator
Turns green when 3G module works normally; Blinks slowly in 3G registration;
Blinks frequently after successful 3G registration.
ALM: Alarm indicator
Turns red when alarm occurs.
4
SIM
SIM card slot.
5
LAN1
RJ45 network interface for debugging.
6
USB1
USB 3.0 interface.
USB2
7
Alarm OUT
2-ch relay signal output.
RS-485
RS-485 interface
Alarm IN
8-ch relay signal input.
8
VGA
VGA output.
9
RS232
Serial interface.
10
A OUT
Audio output.
11
V OUT
Video output.
12
LINE
Two-way audio input.
13
LAN2
M12 network interface for connecting IP cameras.
14
110 VDC
Power supply.
15
Lock
Hard drive lock.
16
Hard Drive Enclosure
3 hard drive caddies for 2.5 inch SATA HDDs/SSDs
