Network Video Recorder User Manual
52
● Ensure the network connection is valid and correct.
Steps
1. Go to Configuration → Camera → Camera.
2. Click .
3. Set camera parameters like IP address, camera password, etc.
4. Click Apply.
Add Network Camera Through PoE
The PoE interfaces enable the device to transfer electrical power and data to connected PoE
cameras. And the PoE interface supports the Plug-and-Play function. Connectable PoE camera
number varies with device models. If you disable a PoE interface, you can also use it to connect to
an online network camera.
Add PoE Camera
Steps
1. Go to Configuration → Camera → Camera → PoE Settings.
2. Enable or disable long network cable mode by selecting Long Distance or Short Distance.
Long Distance
Long-distance (100 to 300 meters) network transmissions via PoE interface.
Short Distance
Short-distance (< 100 meters) network transmission via PoE interface.
Note
● The PoE ports are enabled with the short distance mode by default.
● The bandwidth of IP camera connected to the PoE via long network cable (100 to 300 meters)
cannot exceed 6 Mbps.
● The allowed max. long network cable may be less than 300 meters depending on different IP
camera models and cable materials.
● When the transmission distance reaches 100 to 250 meters, you must use the CAT5e or CAT6
network cable to connect with the PoE interface.
● When the transmission distance reaches 250 to 300 meters, you must use the CAT6 network
cable to connect with the PoE interface.
