4.26 Central Brake and Steer—Pedal Assemblies
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 59
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
4.26 Central Brake and Steer—Pedal Assemblies
Tools required: 2.5 mm hex wrench
5 mm hex wrench
13 mm nut driver
Rubber mallet
Removal
1. Disconnect the battery cable from the control board (refer to procedure 4.7
on page 4-16).
Disconnect the bed from its power source. Failure to do so could cause
injury or equipment damage.
2. Disconnect the bed from its power source.
3. Put the central brake and steer pedals (A) in the neutral position (see figure
4-27 on page 4-60).
4. Remove the two screws (B) that attach the two pedals (A) to the hex rod
(C).
5. Remove the two pedals (A) from the hex rod (C).
6. Loosen the two setscrews (D) that attach the two metal bushings (E) to the
hex rod (C).
It is not necessary to remove the setscrews.
7. Remove the two metal bushings (E) and the two plastic bushings (F) from
the hex rod (C).
8. Loosen the setscrews (G) in the two rocker arms (H).
9. Push the hex rod (C) fully out of the bed frame (I).
10. Remove the bolts (J) and nuts (K) that attach the two head linkages (L) and
one foot linkage (M) to the two rocker arms (H).
