7.2 Trapeze Support—P846F
Chapter 7: Accessories
7
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 7 - 5
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
Removal
1. Loosen and remove the four bolts (A) and the two backing plates (B).
2. Remove the trapeze support (A) from the bed frame (D).
