4.17 Siderail Slide Bracket
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 40 Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed,
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
4.17 Siderail Slide Bracket
Tools required: 5 mm hex wrench
Wire cutters
Removal
Disconnect the bed from its power source. Failure to do so could cause
injury or equipment damage.
1. Disconnect the bed from its power source.
2. Disconnect the battery cable from the control board (refer to procedure 4.7
on page 4-16).
3. Remove the two screws (A) that attach the siderail (B) to the bed (see
figure 4-17 on page 4-41).
4. Pull the slide bracket (C) out of the siderail (B) (see figure 4-17 on page 4-
41).
