Sleep Surface
Chapter 5: Parts List
Page 5 - 24 Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed,
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
Sleep Surface
Figure 5-7. Sleep Surface
Table 5-8. Sleep Surface
Item Number Part Number Quantity Description
1 131469 1 Head panel, electric, standard length
2 131470 1 Head panel, electric, short length
3 131471 1 Head panel, manual, standard length
4 131472 1 Head panel, manual, short length
5 131441 1 Seat panel
6 131473 1 Knee panel
7 131474 1 Foot panel
8 151403 1 Mattress stop
9 141129 12 Pivot blocks and screws
10 141134 6 Sleep surface pivot bolt and E clip
Not shown 131468 2 Pad, foot section
