4.4 Trendelenburg or Reverse Trendelenburg Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 11
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
Replacement
1. Install the screw (H), lockwasher (I), and nut (J) to attach the retainer (K)
to the mount (L).
2. Install the stop (M) between the torque tubes (O).
Look at the opposite assembly (Trendelenburg or Reverse Trendelenburg) to
see how it is attached to the bed.
3. Insert the Trendelenburg rod (C) into the trip lever (E).
4. Install the retaining ring (B) to attach the Trendelenburg rod (C) to the trip
lever (E).
5. Install the retaining ring (F) to attach the Trendelenburg rod (C) to the
switch (G).
6. Make sure the mechanical linkage engages correctly.
7. Make sure the stop (M) is wedged in between the two torque tubes (O)
when either the Trendelenburg or Reverse Trendelenburg handle (G) is
engaged.
8. Remove the bed supports.
9. Connect the battery cable to the control board (refer to procedure 4.7 on
page 4-16).
10. Connect the bed to the correct power source.
11. Do the “Function Checks” on page 2-2.
