4.5 Trendelenburg and Reverse Trendelenburg Indicators
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 13
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
3. Lower the bed until it stops moving. The bed is now at 0° Trendelenburg
and Reverse Trendelenburg.
Use care when you remove the indicator caps. Failure to do so could
cause damage the indicator cap.
4. If the indicator cap (A) is installed, carefully remove it.
5. Align the mark on the indicator cap (A) with the 0° marks on the angle
indicator label (B).
6. Put the indicator cap (A) in the lift arms (B).
7. To disengage the Trendelenburg, raise the bed to the highest position.
8. Do the “Function Checks” on page 2-2.
