4.13 Head or Knee Crank Rod and Drive Screw Assembly (Manual Model Only)
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 31
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
12. Remove the two bolts (L) that attach the drive screw assembly (H) to the
bed frame (B).
Replacement
1. Do the removal procedure in the reverse order.
2. Do the “Function Checks” on page 2-2.
