Accessories
TotalCare® Bariatric Bed and TotalCare® Bariatric Plus Therapy System 71
User Manual (143434 REV 8)
Seat Belt—P1926B
The Seat Belt is adjustable, which allows the caregiver to adjust the Seat Belt to the size
of the patient. Holes, located on both sides of the bed near the center, accommodate
installation of the Seat Belt.
WARNING:
Do not articulate the head section with the patient buckled with the
Seat Belt. Patient injury can occur.
WARNING:
Do not use the Seat Belt as a restraint device. The Seat Belt is only to maintain correct
patient positioning in the chair position.
Removable IV Pole—P2217
The IV pole is a removable, telescopic pole that installs at any of the four corners of
the bed in the holes provided. The IV pole can hold 25 lb (11kg).
To install the standard IV pole, insert and rotate a quarter-turn clockwise. Removal is
opposite of installation.
CAUTION:
Removable IV Pole SWL is 25 lb (11.3 kg). Exceeding the SWL
can result in equipment damage.
CAUTION:
When lowering the upper section of an IV pole, always grasp and hold the upper section of
the pole before pulling the release knob.
NOTE:
Added height recommended for gravity drain applications.
Medical Articulated Arm (P3670A01 and
P3670A05)
The medical articulated arm is used to hold breathing circuits and
pressure transducers and keep them in position. The P3670A01 is
the tube holder configuration, and the P3670A05 is the transducer
configuration. Both configurations require the P3636 bracket
assembly for installation on the bed. The arms can be mounted on
either or both corners of the head section. Refer to the
manufacturer’s instructions for operation.
