J1
1 Brush Motor 3 Black Negative
2 Brush Motor 3 Red Positive
3 Vacuum Motor 3 Red Positive
4 Vacuum Motor 3 Black Negative
J2
1 Traction Motor 3 Black Negative
2 Traction Motor 3 Red Positive
J3
2 Chemical Pump / recycle pump 10 Green
3 Electrobrake 10 Brown
4 Solenoid Valve 10 Orange
5 Water Pump 10 Red
7 Chemical Pump / recycle pump 10 Orange
8 Electrobrake 10 L.Blue
9 Solenoid Valve 14 Yellow
10 Water Pump 10 Black
11 Sweeping 10 Purple
J10
1 FFM Communication 3 White Receiving
2 FFM Communication 3 Brown Transmitting
3 FFM Communication 3 Green
4 FFM Communication 3 Yellow
J6
1 Display Communication 11 White Receiving
2 Display Communication 11 Brown Transmitting
3 Display Communication 11 Green Negative
4 Display Communication 11 Yellow
