J7
1 Key In 12 Viola Positive
2 Power 13 Yellow Negative
3 Backwards 14 Red Negative
4 Safety Microswitch 12 L. Blue
5 Wand activation switch 14 Orange
6 Gun activation switcha 12 Blue
7 Brush 1 Alarm 15 L. Blue
8 Backwards 14 Rose
9 Extra pressure 13 Orange
10 Gun 12 Red
11 Traction Potentiometer 21 Yellow
12 Traction Potentiometer 21 Brown
13 Traction Potentiometer 21 Green
14 Empty Solution floater 14 White
15 Empty Recovery floater 14 Black
16 Full Recovery floater 22
17 Brush 2 Alarm 14 White
18 Empty Recovery floater 14 Red
19 Empty Solution floater 14 L. Blue
20 Battery charger 14 Green
J8
1 Squeegee Actuator (M1) 3 Red Receiving
4 Squeegee Actuator (M2) 3 Black Receiving
J9
1 Bruch deck Actuator (M4) 20 Brown Receiving
2 Extrapressure / Pressure Lev.1 (BTO) 20 Yellow
3 Pressure Lev.3 (BTO)
4 Bruch deck Actuator (M4) 20 L. Blue Receiving
5 Pressure Lev.2 (BTO)
6 Extrapressure 20 Rose
34
