Hilti DX 9–ENP Operating Instructions

English 9
Display Explanation
The max. number of fasteners driven has been reached. The tool must
be cleaned.
The black square at the lower edge on the right indicates that demo
mode is active. In this case, the information in the display does not
reflect the actual status of the tool.
The Hilti Connect smartphone app can be used to deactivate the
demo mode. Demo mode is automatically deactivated after a period of
15 minutes.
3.7 Items supplied
Fastening tool, toolbox, cleaning set, scraper, ramrod, Hilti lubricant spray, operating instructions.
Other system products approved for use with this product can be found at your local Hilti Store or
online at: www.hilti.group.
4 Technical data
4.1 Technical data
DX 9–ENP
Weight in accordance with EPTA procedure 01
12.5 kg
Dimensions (L × W × H)
985 mm × 365 mm × 175 mm
Magazine capacity
40 nails / 40 cartridges
Suitable cartridges
6.8/18 M40 red, black, blue
Suitable fasteners
XENP 19
Fastener driving rate
1,200 rev/h
Thickness of the supporting steel
≥ 6 mm
Compression stroke
89 mm
Contact pressure
≥ 250 N
Application temperature (ambient temperature)
−15 ℃ … 50 ℃
4.2 Noise information
The noise values listed were determined under the following conditions:
General conditions for noise measurements
Direct fastening tool DX 9–ENP
Model Series
Caliber 6.8/18 black
Power setting 4
Application Fastening to steel plate (Brinell
hardness 610 N/mm
2
) using the
XENP19 L15MXR
Noise information in accordance with EN 15895
Emission sound pressure level (L
pA
)
103 dB(A)
Uncertainty for the sound pressure level (K
pA
)
2 dB(A)
Sound (power) level (L
WA
)
113 dB(A)
Uncertainty for the sound power level (K
WA
)
2 dB(A)
Peak sound pressure emission level (L
pC, peak
)
137 dB(C)
Uncertainty for the peak sound pressure level (K
pCpeak
)
2 dB(C)
