3 Product Description
X-AI 32 01
Page 12 of 58
HI 801 021 E Rev. 4.00
3.4.1 Block
Diagram
The following block diagra
m illustra
tes the structure of
the module.
Field Side: Transmitter and Wired Contacts
External Transmitter Supply
Interface
Safety-Related Processor System
System
Busses
Figure 2:
Block Diagram
11
13
