3.6.8 Pin Assignment for X-CB 008 05
HIMA provides ready-made system cables for use with this connector board,
see Chapter
3.7. The cable plug and the connector boards are coded.
i
Connector pin assignment!
The following table describes the connector pin assignment of the system cable plug.
Lead marking based on DIN 47100:
e d c b a
Row
Signal Color Signal Color Signal Color Signal Color Signal Color
1 S32+ RD
2)
AI_R32+
PK-BN
1)
AI32+
WH-PK
1)
reserv.
YE-GY
2)
2 S31+ BU
2)
AI_R31+
GY-BN
1)
AI31+
WH-GY
1)
reserv.
GY-GN
2)
3 S30+ PK
2)
AI_R30+
YE-BN
1)
AI30+
WH-YE
1)
reserv. BN-BK
2)
4 S29+ GY
2)
AI_R29+
BN-
GN
1)
AI29+
WH-GN
1)
reserv. WH-BK
2)
5 S28+ YE
2)
AI_R28+
RD-
BU
1)
AI28+ GY-PK
1)
Not used
6 S27+ GN
2)
AI_R27+ VT
1)
AI27+ BK
1)
Not used
7 S26+ BN
2)
AI_R26+ RD
1)
AI26+ BU
1)
Not used
8 S25+ WH
2)
AI_R25+ PK
1)
AI25+ GY
1)
Not used
9 S24+ RD-BK
1)
AI_R24+ YE
1)
AI24+ GN
1)
Not used
10 S23+ BU-BK
1)
AI_R23+ BN
1)
AI23+ WH
1)
Not used
11 S22+ PK-BK
1)
AI_R22+ RD-BK AI22+ BU-BK Not used
12 S21+ GY-BK
1)
AI_R21+ PK-BK AI21+ GY-BK Not used
13 S20+ PK-RD
1)
AI_R20+ PK-RD AI20+ GY-RD Not used
14 S19+ GY-RD
1)
AI_R19+ PK-BU AI19+ GY-BU Not used
15 S18+ PK-BU
1)
AI_R18+ YE-BK AI18+ GN-BK Not used
16 S17+ GY-BU
1)
AI_R17+ YE-RD AI17+ GN-RD Not used
17 S16+ YE-BK
1)
AI_R16+ YE-BU AI16+ GN-BU S- BN-RD
2)
Not used
18 S15+ GN-BK
1)
AI_R15+ YE-PK AI15+ PK-GN S- WH-RD
2)
Not used
19 S14+ YE-RD
1)
AI_R14+ YE-GY AI14+ GY-GN S- BN-BU
2)
Not used
20 S13+ GN-RD
1)
AI_R13+ BN-BK AI13+ WH-BK S- WH-BU
2)
Not used
21 S12+ YE-BU
1)
AI_R12+ BN-RD AI12+ WH-RD S- PK-BN
2)
Not used
22 S11+ GN-BU
1)
AI_R11+ BN-BU AI11+ WH-BU S- WH-PK
2)
Not used
23 S10+ YE-PK
1)
AI_R10+ PK-BN AI10+ WH-PK S- GY-BN
2)
Not used
24 S9+ PK-GN
1)
AI_R9+ GY-BN AI9+ WH-GY S- WH-GY
2)
Not used
25 S8+ YE-GY
1)
AI_R8+ YE-BN AI8+ WH-YE AI- YE-BN
2)
Not used
26 S7+ GY-GN
1)
AI_R7+ BN-GN AI7+ WH-GN AI- WH-YE
2)
Not used
27 S6+ BN-BK
1)
AI_R6+ RD-BU AI6+ GY-PK AI- BN-GN
2)
Not used
28 S5+ WH-BK
1)
AI_R5+ VT AI5+ BK AI- WH-GN
2)
Not used
29 S4+ BN-RD
1)
AI_R4+ RD AI4+ BU AI- RD-BU
2)
Not used
30 S3+ WH-RD
1)
AI_R3+ PK AI3+ GY AI- GY-PK
2)
Not used
31 S2+ BN-BU
1)
AI_R2+ YE AI2+ GN AI- VT
2)
Not used
32 S1+ WH-BU
1)
AI_R1+ BN AI1+ WH AI- BK
2)
Not used
1)
Additional orange ring if one lead marking color is repeated for the first time.
2)
Additional violet ring if one lead marking color is repeated for the second time.
Table 16: Pin Assignment for the System Cable Plug
