HIMA X-AI 32 01 User Manual

X-AI 32 01 3 Product Description
HI 801 021 E Rev. 4.00 Page 21 of 58
3.6.4 Terminal Assignment for Connector Boards with Screw Terminals
Pin no. Designation Signal Pin no. Designation Signal
1 01a S1+ 1 02a S2+
2 01b AI1+ 2 02b AI2+
3 01c AI1- 3 02c AI2-
4 03a S3+ 4 04a S4+
5 03b AI3+ 5 04b AI4+
6 03c AI3- 6 04c AI4-
7 05a S5+ 7 06a S6+
8 05b AI5+ 8 06b AI6+
9 05c AI5- 9 06c AI6-
10 07a S7+ 10 08a S8+
11 07b AI7+ 11 08b AI8+
12 07c AI7- 12 08c AI8-
Pin no. Designation Signal Pin no. Designation Signal
1 09a S9+ 1 10a S10+
2 09b AI9+ 2 10b AI10+
3 09c AI9- 3 10c AI15+
4 11a S11+ 4 12a S12+
5 11b AI11+ 5 12b AI12+
6 11c AI11- 6 12c AI12-
7 13a S13+ 7 14a S14+
8 13b AI13+ 8 14b AI14+
9 13c AI13- 9 14c AI14-
10 15a S15+ 10 16a S16+
11 15b AI15+ 11 16b AI16+
12 15c AI15- 12 16c AI16-
Pin no. Designation Signal Pin no. Designation Signal
1 17a S17+ 1 18a S18+
2 17b AI17+ 2 18b AI18+
3 17c AI17- 3 18c AI18-
4 19a S19+ 4 20a S20+
5 19b AI19+ 5 20b AI20+
6 19c AI19- 6 20c AI20-
7 21a S21+ 7 22a S22+
8 21b AI21+ 8 22b AI22+
9 21c AI21- 9 22c AI22-
10 23a S23+ 10 24a S24+
11 23b AI23+ 11 24b AI24+
12 23c AI23- 12 24c AI24-
