X-AI 32 01 3 Product Description
HI 801 021 E Rev. 4.00 Page 19 of 58
Male Connector Recess
Prepared Male Connector Recess
Coding Wedge
Guideway for Coding Wedge
Figure 5: Coding Example
Coded I/O modules can be plugged in to uncoded connector boards. Uncoded I/O modules
cannot be plugged in to coded connector boards.
3.6.2 Coding of X-CB 008 Connector Boards
a7 a13 a20 a26 c7 c13 c20 c26
X X X
Table 12: Position of Coding Wedges
