HIMA X-AI 32 01 User Manual

4 Start-up X-AI 32 01
Page 38 of 58 HI 801 021 E Rev. 4.00
Name
Data
type
R/W Description
SP HIGH DINT W Lower limit of high level
SP HIGH (switching point HIGH) is the limit value: if this limit
is exceeded, the module detects a HIGH and switches the
Channel LED on.
Restriction: SP LOW ≤ SP HIGH
Default setting: 40 500 (4.05 mA)
-> Ch. value [BOOL] [BOOL] R Boolean channel value in accordance with the limits
SP LOW and SP HIGH.
Ton [µs] UDINT W Time on delay
The module only indicates a level change from LOW to HIGH
if the HIGH level is present for longer than the configured
time t
on
.
Important: The maximum reaction time T
R
(worst case) for
this channel is extended by the delay time, since a signal
change is not detected until the delay time has expired.
Range of values: 0…(2
32
-1)
Default setting: 0
Toff [µs] UDINT W Time off delay
The module only indicates a level change from HIGH to LOW
if the LOW level is present for longer than the configured time
t
off
.
Important: The maximum reaction time T
R
(worst case) for
this channel is extended by the delay time, since a signal
change is not detected until the delay time has expired.
Range of values: 0…(2
32
-1)
Default setting: 0
-> State LL BOOL R TRUE: Value associated with the LL event state
FALSE: Value out of the range associated with the LL event
state
-> State L BOOL R TRUE: Value associated with the L event state
FALSE: Value out of the range associated with the L event
state
-> State N BOOL R TRUE: Value associated with the N (normal) event state
FALSE: Value out of the range associated with the N (normal)
event state
-> State H BOOL R TRUE: Value associated with the H event state
FALSE: Value out of the range associated with the H event
state
-> State HH BOOL R TRUE: Value associated with the HH event state
FALSE: Value out of the range associated with the HH event
state
Redund. BOOL W Requirement: The redundant module must be configured.
Acivated: Activate the channel redundancy for this channel
Deactivated: Deactivate the channel redundancy for this
channel
Default setting: Deactivated.
Redundancy value BYTE W Setting for determining the redundancy value.
 Min
 Max
 Average
Default setting: Max
It is only displayed in the redundancy group tab!
Table 23: Tab: I/O Submodule CI32_01:Channels in the Hardware Editor
