X-AI 32 01
3 Product Description
HI 801 021 E Rev. 4.00
Page 25 of 58
3.6.7
Connector Board Redundancy us
ing Two System Base Plates
I/O Module Plug
Connection to the Field Zone (Cable
Plug in Row 1)
Connection to the Field Zone (Cable
Plug in Row 32)
Coding for Cable Plugs
Figure 8:
Connector Board with Cable Plug, Varia
nt X-CB 008 05
24
26
