X-AI 32 01
3 Product Description
HI 801 021 E Rev. 4.00
Page 23 of 58
3.6.5
Pin Assignment for Connec
tor Boards with Cable Plug
Mono Redundant
Three-fold
redundant
X-CB 008 03
X-CB 008 04
X-CB 008 07
X-CB 019 03
X-CB 019 04
I/O Module Plug
Connection to the Field Zone (Cable Plug in
Row 1)
Connection to the Field Zone (Cable Plug in
Row 32)
Coding for Cable Plugs
Figure 7:
Connector Boards with Cable Plug
