HIMA X-AI 32 01 User Manual

3 Product Description X-AI 32 01
Page 28 of 58 HI 801 021 E Rev. 4.00
The system cable is available in the following standard variants:
System cable Description Length
X-CA 005 01 8 8 m
X-CA 005 01 15 15 m
X-CA 005 01 30
Coded cable plugs on both sides
30 m
Table 18: Available System Cables X-CA 005
3.7.2 System Cable X-CA 009
The X-CA 009 system cable is used to connect the X-CB 008 05 connector board to the
field zone via field termination assemblies.
General
Cable LIYCY-TP 58 x 2 x 0.14 mm²
Wire Finely stranded
Average outer diameter (d) approx. 18.3 mm
Minimum bending radius
Fixed laying
Flexible application
5 x d
10 x d
Combustion behavior
Flame resistant and self-extinguishing in
accordance with IEC 60332-1-2, -2-2
Length 8…30 m
Color coding Based on DIN 47100, see Table 16.
Table 19: Cable Data X-CA 009
The system cable is available in the following standard variants:
System cable Description
Length 448
kBytes
X-CA 009 01 8 8 m
X-CA 009 01 15 15 m
X-CA 009 01 30
Coded cable plugs on both sides
30 m
Table 20: Available System Cables X-CA 009
3.7.3 Cable Plug Coding
The cable plugs are equipped with three coding pins. Cable plugs only match connector
boards and FTAs with the corresponding recesses, see
Figure 7.
