3.6.6 Pin Assignment for Connector Boards with Cable Plug
HIMA provides ready-made system cables for use with these connector boards, see
Chapter
3.7. The cable plug and the connector boards are coded.
i
Connector pin assignment!
The following table describes the connector pin assignment of the system cable plug.
Lead marking based on DIN 47100:
c b a
Row
Signal Color Signal Color Signal Color
1 S32+ PK-BN
1)
AI32+ WH-PK
1)
Reserved YE-BU
1)
2 S31+ GY-BN
1)
AI31+ WH-GY
1)
Reserved GN-BU
1)
3 S30+ YE-BN
1)
AI30+ WH-YE
1)
Reserved YE-PK
1)
4 S29+ BN-GN
1)
AI29+ WH-GN
1)
Reserved PK-GN
1)
5 S28+ RD-BU
1)
AI28+ GY-PK
1)
Not used
6 S27+ VT
1)
AI27+ BK
1)
Not used
7 S26+ RD
1)
AI26+ BU
1)
Not used
8 S25+ PK
1)
AI25+ GY
1)
Not used
9 S24+ YE
1)
AI24+ GN
1)
Not used
10 S23+ BN
1)
AI23+ WH
1)
Not used
11 S22+ RD-BK AI22+ BU-BK Not used
12 S21+ PK-BK AI21+ GY-BK Not used
13 S20+ PK-RD AI20+ GY-RD Not used
14 S19+ PK-BU AI19+ GY-BU Not used
15 S18+ YE-BK AI18+ GN-BK Not used
16 S17+ YE-RD AI17+ GN-RD Not used
17 S16+ YE-BU AI16+ GN-BU Not used
18 S15+ YE-PK AI15+ PK-GN Not used
19 S14+ YE-GY AI14+ GY-GN Not used
20 S13+ BN-BK AI13+ WH-BK Not used
21 S12+ BN-RD AI12+ WH-RD Not used
22 S11+ BN-BU AI11+ WH-BU Not used
23 S10+ PK-BN AI10+ WH-PK Not used
24 S9+ GY-BN AI9+ WH-GY Not used
25 S8+ YE-BN AI8+ WH-YE AI- YE-GY
1)
26 S7+ BN-GN AI7+ WH-GN AI- GY-GN
1)
27 S6+ RD-BU AI6+ GY-PK AI- BN-BK
1)
28 S5+ VT AI5+ BK AI- WH-BK
1)
29 S4+ RD AI4+ BU AI- BN-RD
1)
30 S3+ PK AI3+ GY AI- WH-RD
1)
31 S2+ YE AI2+ GN AI- BN-BU
1)
32 S1+ BN AI1+ WH AI- WH-BU
1)
1)
Additional orange ring if one lead marking color is repeated.
Table 15: Pin Assignment for the System Cable Plug
