2.3 Other Electrical and Physical Data
1) Environmental temperature and Humidity
Operation: 0 to 40℃ (SM-8213/8215),80% RH or less (non-condensating)
5 to 35℃ (SM-8220),80% RH or less (non-condensating)
Storage: 5 to 45℃,80% RH or less(non-condensating)
2) Power Requirements
AC 100 V, 120 V, 220 V, ±10%, 240 V +10 V, 10% 50/60 Hz
3) Power Consumption
Approx. 25 VA
4) Dimensions
Approx. 284 (W) × 139 (H) × 215 (D) mm
Also, see 11. EXTERNAL VIEW for external appearance.
5) Weight
Approx. 4.3 kg
2.4 Optional Functions and Accessories
In addition to the standard accessories shown in 1.1 Unpacking and Checking of the Contents
and Table 1.1 List of Standard Accessories, the following two groups of optional accessories are
available to expand the applications of the SM-8200 Series super megohmmeters.
1) Options – designed exclusive for the SM-8200 Series
Name Model
Printer 9442
2) Options – designed for common to SM-8200 Series, SM-8216, and
SM-8000 Series super megohmmeters.
Name Model Description
Electrode for plate samples SME-8310
Electrode for plate samples SME-8311
With surface/volumetric
selector, interlock function
Weight electrode SME-8320 With surface/volumetric
Selector. Needs shield box.
Shield box SME-8350 Electromagnetic shielding
Electrode for surface
resistance measurement
SME-8301 Simplified electrode for surface
resistance measurement
Electrode for surface
resistance measurement
SME-8302 Simplified electrode for curved surface
resistance measurement
Electrodes for liquid sample
measurement
SME-8330 Capacity, approx. 25 mL
Electrode constant: Approx. 500 cm
Surface/Volume
Resistance Measurement
Electrode
SM9001 Surface/volume resistance
measurement of antistatic flooring,
etc.
Electrodes for chip
capacitors
SME-8360 Chip capacitor measurement
