4.5 Meanings of the Status and Mode Notices
This describes the meanings of the status and mode notice in the lower left
corner of the LCD display.
1) LOCK (Interlocking): The test voltage applying circuit is interlocked, an
measurement is not ready, yet. This notice is shown when the
interlocking function is in use, but the HV-EN plug or measuring rod
plug is not plugged into the connector.
When the LOCK is shown, the MEASURE and CHARGE switches become
inoperative.
2) CAL1 (Calibration-1): This is shown when the RANGE selector switch is set
to the CAL position.
3) CAL2 (Calibration-2): This is shown when the SELECT switch is pushed
while the CAL1 notice is shown.
4) C. SET (Measuring voltage charging time setting mode): The time can be
adjusted within a range from 0 to 999 seconds.
5) M. SET (Measuring time setting mode): The time can be adjusted within a
range from 0 to 999 seconds.
6) COMP (Comparison judgment value setting mode): The value can be set
within a range from the minimum value for the range to 10 times the
value.
7) BUZZ (Buzzer ON/OFF setting mode): The buzzer can be set ON or OFF when
the resultant comparison judgment is NO.
