The devices differ with regard to their design, the standards they support and
their certifications, as shown in the table below:
1.1.1 BAT-F types
The BAT-F devices have protection class IP67. The devices are particularly
suitable for field use. You can mount the devices on a pole or on a flat surface
(e.g. wall).
BAT-X2 types
BAT-X2 devices are suitable for use in environments with the danger of
explosions (Ex zone 2 areas according to ATEX 95 / ATEX 100a).
1.1.2 BAT-Rail types
BAT-Rail devices are suitable for use on DIN rails and on machines in the
production area, as well as on vehicles. You can snap them quickly and
simply onto the DIN rail or mount them on a flat surface (e.g. wall). With 5-
way redundant voltage supply (4-way for the BAT-Client) and a vibration-
resistant metal housing, the devices provide high operational reliability.
1.1.3 BAT54 types
The BAT54 is a dual-band industrial wireless LAN access point/client with
two independent WLAN modules in accordance with IEEE 802.11a/b/g/h and
IEEE 802.11i. In particular, the devices support the security mechanisms,
authentication procedures and data encryptions defined in the IEEE 802.11i
standard.
Design
Indoor
BAT-Rail types
Outdoor
BAT-F types
Radio standards
801.11 a/b/g/h/i
BAT54 types
Ex range
BAT X2 types
BAT54-Rail
BAT54-Rail-Client
BAT54-Rail Single
BAT54-F
BAT54-F Single
BAT54-F Client
BAT54-F X2
BAT54-F Single X2
BAT54-F Client X2
802.11 a/b/g/h/i/n
BAT300 types
BAT300-Rail BAT300-F BAT300-F X2
Table 3: Range of applications for BAT device types
