Page #62 background imageLoading...
Page #62 background image
62
Installation BAT
Release
05
03/2013
3 Technical data
General technical data
Description BAT54 types Dual-band industrial WLAN access point/client in
accordance with IEEE 802.11a/b/g/h and IEEE 802.11i
BAT300 types Dual-band industrial high-performance WLAN access
point/client in accordance with IEEE 802.11a/b/g/h and
802.11n
BAT-Rail types Used on DIN rail, 5-way (4-way for BAT-Client types)
redundant voltage supply, vibration-resistant metal housing
BAT-F types Mounted on pole or flat surface (wall), protection class IP67,
especially for use in field and in environments with the
danger of explosion
Port type and
number
BAT54-F 2 x WLAN interfaces, up to 8 SSIDs per WLAN interface,
1 x LAN port 10/100BASE-TX, Autosensing
BAT54-F Single 1 x WLAN interface, up to 8 SSIDs per WLAN interface,
2 x LAN ports 10/100BASE-TX, Autosensing
BAT54-F Client 1 x WLAN interface,
1 x LAN port 10/100BASE-TX, Autosensing
BAT300-F 1 x WLAN interface, up to 8 SSIDs per WLAN interface,
1 x LAN port 10/100BASE-TX, Autosensing
BAT54-Rail 2 x WLAN interfaces, up to 8 SSIDs per WLAN interface,
2 x LAN ports 10/100BASE-TX, Autosensing
BAT54-Rail Single 1 x WLAN interface,
1 x LAN port 10/100BASE-TX, Autosensing
BAT54-Rail Client 1 x WLAN interface,
1 x LAN port 10/100BASE-TX, Autosensing
BAT300-Rail 1 x WLAN interface, up to 8 SSIDs per WLAN interface,
2 x LAN ports 10/100BASE-TX, Autosensing
Dimensions
W x H x D
BAT-F, BAT-F FCC
BAT-F X2, BAT-F X2 FCC
BAT-Rail
261 mm x 56 mm x 212 mm
273 mm x 59 mm x 310 mm
85 mm x 105 mm x 135 mm
Weight BAT-F, BAT-F FCC
BAT-F X2, BAT-F X2 FCC
BAT-Rail
approx. 2000 g
approx. 5200 g
approx. 770 g
Mounting BAT-F
BAT-Rail
Wall and pole mounting
DIN rail and wall mounting
Power supply
Operating voltage
BAT-F (excl.
BAT54-F Single)
BAT-F
BAT-Rail
2 x 24 VDC -20% to + 25%
at 5-pin “Power” plug
Power over Ethernet acc. to IEEE 802.3af,
Mode A, Class 0: + 36 VDC to 57 VDC / max. 8.2 W at
“Ethernet” socket
All power supplies redundant with each other
2 x 24 V DC; 12 V DC with external power unit (230 V)2
x (1 x for BAT-Client types) Power over Ethernet acc. to
IEEE 802.3af
All power supplies redundant with each other
Overload current
protection at input
Non-replaceable fuse
