Hirschmann BAT series User Manual

Installation BAT
Release 05 03/2013
63
 Radio technology
Insulation voltage
between operating
voltage connectors
and housing
800 V DC
Protective elements limit the insulation voltage to
45 V DC.
Environment Storage temperature
(ambient air
temperature)
Humidity
Atmospheric pressure
-30 °C to +70 °C ( -22 °F to +158 °F)
10% to 95% (non-condensing)
up to 2,000 m (795 hPa)
Operating
temperature
BAT54/300-Rail
BAT54/300-F(except
BAT300-F X2)
BAT300-F X2
Surrounding air -30 °C to +50 °C
Surrounding air -30 °C to +55 °C
(temporarily up to +70 °C acc. to EN50155)
Surrounding air -20 °C to +55 °C
Pollution degree BAT-Rail 2
Protection class BAT-F:
IP67 (EN 60529)
Type 1 (NEMA)
BAT-Rail:
IP40 (EN 60529)
Open type (NEMA)
Sturdy metal housing designed for mounting on a
pole or on a flat surface (e.g. wall).
Sturdy metal housing designed for mounting on a
DIN rail or on a flat surface (e.g. wall).
Antenna
connection
BAT54-F Four antenna connections
BAT54-F Single Two antenna connections
BAT54-F Client Two antenna connections
BAT300-F Three antenna connections
BAT54-Rail Four Reverse SMA antenna connections (sockets)
BAT54-Rail Single Two Reverse SMA antenna connections (sockets)
BAT54-Rail Client Two Reverse SMA antenna connections (sockets)
BAT300-Rail Three Reverse SMA antenna connections (sockets)
Range BAT... Up to 20 km with external antennas (depending on antenna
used, frequency range and data rate)
Encryption BAT... IEEE 802.11i/WPA2 with passphrase or 802.1x and
hardware-accelerated AES, user authentication with
802.1x/EAP or LEPS, IEEE 802.1x supplicant in client
mode, WPA/TKIP, WEP, access control lists, WLAN port
and protocol filters, RADIUS client and server, built-in
firewall with QoS, port filter, protocol filter, IDS and DoS
protection, PMK caching and pre-authentication for fast
roaming with IEEE 802.1x
Frequency
range
BAT54 2 x (1 x for BAT-Client and BAT-Single types) independent
radio modules, each 2.4 Ghz and 5 GHz: 2400-2483.5 MHz
(ISM) and 5170-5810 MHz
BAT300 1 x radio module, supported by 2.4 GHz and 5 GHz: 2400-
2483.5 MHz (ISM) and 5170-5850 MHz
BAT...BG(N) Supports 2.4 GHz: 2400-2483.5 MHz (ISM)
Modulation
technology
BAT... 22M0F7D (DSSS/OFDM) at 2.4 GHz
20M0G7D (OFDM) at 5 GHz
Radio topology BAT...
BAT Client
WLAN access point, bridge, router, point-to-point, client,
client-bridge mode, fixed mesh with RSTP
WLAN client, client-bridge mode
