2.17 Display elements
After the operating voltage is applied, the software starts and initializes itself.
The device then performs a self-test. During this process, the LEDs light up.
The process takes a number of seconds.
Figure 18: Display elements for the BAT54-F, BAT54-F Single,
BAT300-F, BAT54-F Client
1 - P (Power)
2 - LS/DA (Ethernet port link status/data)
3 - WLAN 1
4 - WLAN 2
5 - NC
BAT54-F Single
WLAN
P
LS/DA
2
LS/DA
1
BAT54-F Client
WLAN
LS/DAP
NC
BAT300-F
LS/DAP
WLAN
NC
BAT54-F
LS/DAP
WLAN
2
WLAN
1
1
3
2
4
1
3
2
2
1
5
2
3
1
3
2
5
