For Use in Hazardous Locations Class I Division 2 Groups A, B ,C ,D:
Only allowed for MSP30 or MS32 model No´s. which are individually labelled ´)2586(,1+$=$5'286/2&$7,216µ
Nonincendive field wiring circuits must be wired in accordance with the
National Electrical Code (NEC), NFPA 70 , article 501.
WARNING - EXPLOSION HAZARD – SUBSTITUTION OF ANY COMPONENTS MAY IMPAIR SUITABILITY FOR
HAZARDOUS LOCATIONS OR EXPLOSIVE ATMOSPHERES.
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN SWITCHED
OFF OR THE AREA IS KNOWN TO BE NON-HAZARDOUS.
*) Notes:
The nonincendive field wiring circuit concept allows interconnection of nonincendive field wiring apparatus and
associated nonincendive field wiring apparatus using any of the wiring methods permitted for unclassified locations when
certain parametric conditions are met.
Capacity: C
a
C
i
+ C
Cable
; Inductivity: L
a
L
i
+ L
Cable
The maximum cable length has to be determined as follows:
(a) max. Cable Length < max. Cable Length < (L
a
-L
i
) / Cable
L
(”Cable
L
“ denotes the inductance per unit length of used cable) and
(b) max. Cable Length < max. Cable Length < (C
a
-C
i
) / Cable
C
(“Cable
C
“ denotes the capacitance per unit length of used cable).
The lower value of (a) and (b) is to apply.
Manufactured in 72654 Neckartenzlingen / Germany by Hirschmann Automation and Control GmbH.
DOM: ww/yyyy (Date of manufactur w - week, Y - year. Refer to the device label).
for Use in Hazardous Locations
Class I Division 2 , Groups A, B, C, D
Rev. 0 Document No.: 000172850DNR Page 2/2
