52
Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release
12
06/2018
2.3 Installing and grounding the device
When you are selecting the installation location, make sure you observe
the climatic threshold values specified in the technical data.
Prevent heat from the surroundings from affecting the device.
Verify that there is at least 4 in (10 cm) of space above and below the
device.
Verify that there is at least 0.8 in (2 cm) of space on the right and left sides
of the device.
2.3.1 Installing the device onto the DIN rail
The device variants featuring customer-specific version with the
characteristic value HH are suitable for mounting on a DIN rail.
Proceed as follows:
Install the device on a horizontally mounted 1.38 inch (35 mm) DIN rail in
accordance with DIN EN 60715.
Insert the upper snap-in guide of the device into the DIN rail and press the
device down against the DIN rail until it snaps into place.
WARNING
FIRE HAZARD
Install the device in a fire enclosure according to EN 60950-1.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
CAUTION
BURNING HAZARD
The surfaces of the device casing may become hot. Avoid touching the
device while it is operating.
If ambient temperatures are ≥113 °F (≥45 °C), exclusively install the device
in “restricted access locations” according to EN 60950-1.
Failure to follow these instructions can result in injury or equipment
damage.
