Hirschmann MSP30

Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release 12 06/2018
31
1Port1(F/O)
2Port2(F/O)
3 Port 3 (Twisted Pair)
4 Port 4 (Twisted Pair)
Table 11: MSM20-S2S2T1T1...
1Port1(F/O)
2Port2(F/O)
3Port 3(F/O)
4Port 4(F/O)
Table 12: MSM20-S4S4S4S4...
1 Port 1 (Twisted Pair)
2 Port 2 (Twisted Pair)
3 Port 3 (Twisted Pair)
4 Port 4 (Twisted Pair)
Table 13: MSM20-T5T5T5T5...
1
2
3
4
1
2
3
4
11
22
33
44
