Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release 12 06/2018
You will find the arrangement and sequence of the slots on the basic device
in the following overview:
Slots MSP30/32-2404... MSP40/42-0028...
110
a
/100/1000 Mbit/s
a. Only for twisted pair connections.
1000/2500 Mbit/s
210
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
310
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
Slots MSP30/32-2404... MSP40/42-0028...
110
a
/100/1000 Mbit/s
a. Only for twisted pair connections.
1000/2500 Mbit/s
210
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
310
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
410
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
510
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
Slots MSP30/32-2404... MSP40/42-0028...
110
a
/100/1000 Mbit/s
a. Only for twisted pair connections.
1000/2500 Mbit/s
210
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
310
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
410
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
510
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
610
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
710
a
/100 Mbit/s 10
a
/100/1000 Mbit/s
1 2 3
1 2 3 4 5
1 2 3 4 5 6
7
