Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release
12
06/2018
47
Input (I) Digital input — none Input voltage: low level
green Lights up Input voltage: high level
Output (O) Digital output — none The output relay is deactivated (idle
status).
green Lights up The output relay is activated.
yellow Flashes 3
times a
period
The synchronization of the digital output
with the assigned input has failed.
LED Display Color Activity Meaning
Table 34: Device status and I/O status for MSM24 I/O module
