Hirschmann MSP30

Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release 12 06/2018
79
Figure 11: MSP30-0804.......HX...
Figure 12: MSP30-1604.......HX...
mm
inch
139,7
5.5
276,6
10.89
173 6.81
131,3
5.17
131,3
5.17
79,5
3.13
79,5
3.13
4,5
0.18
Ø
mm
inch
139,7
5.5
173 6.81
353,8
13.93
120,25
4.73
99,25
3.91
120,3
4.74
79,5
3.13
79,5
3.13
4,5
0.18
Ø
