Hirschmann MSP30

Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release 12 06/2018
81
Figure 15: Dimensions for media module MSM46-T1T1T1T1... with characteristic
value HH (with terminal block for external PoE supply voltage)
Figure 16: Dimensions for media modules with customer-specific version
characteristic value HX
5.22
132,49
38,2
mm
inch
1.5
117,8
4.64
38,2
mm
inch
117,8
4.64
1.5
132,49
5.22
157,49
6.2
