40
PowerMICE
Release
01
04/2014
2.4 Basic set-up
The IP parameters must be entered when the device is installed for the first
time. The device provides 6 options for configuring IP addresses:
Entry via V.24 connection
Entry using the HiDiscovery protocol via the application HiDiscovery or
Industrial HiVision
Configuration via BOOTP
Configuration via DHCP
Configuration via DHCP Option 82
Auto Configuration Adapter
Further information on the basic settings of the device can be found in the
“Basic Configuration” user manual on the CD ROM.
Default settings
IP address: The device looks for the IP address using DHCP
Password for management:
Login: user; password: public (read only)
Login: admin; password: private (read and write)
V.24 data rate: 9,600 Baud
Ring redundancy: deactivated
Ethernet ports: link status is not evaluated (signal contact)
Optical 100 Mbit/s ports: 100 Mbit/s, full duplex
All other ports: autonegotiation
Ring manager disabled
Stand-by coupling: disabled
The configuration is controlled via the software
USB interface
The USB socket has an interface for the local connection of an
AutoConfiguration Adapter ACA 21-USB. It is used for saving/loading the
configuration and for updating the software.
V.24 interface (external management)
The V.24 interface is an RJ11 socket.
Contact number Signal name
1VCC
2 - Data
3 + Data
4 Ground
