Hisense AHM-080FJFAA - Installation of Water Module; Initial Check

31
320
75
94
74
59
520
800
60
600
150
150
70
800
520
7. Installation of Water Module
7.1 Initial Check
● See dimension of water module in Fig.7.1 (unit:
mm).
Fig.7.1a Dimension of Water Module
Fig.7.1b Dimension of Water Module
● Install water module to a place where it is easy
to operation and maintenance, seen in Fig.7.2.
Fig.7.2a Installation and Maintenance Space
Fig.7.2b Installation and Maintenance Space
Selection of installation location:
● Indoor installation is made in selected special
machine room, closed balcony, basement,
corridor, equipment room or other indoor area
with sufficient space.
● Installation surface must be flat, vertical and
nonflammable wall and bear running weight of
unit (76kg).
● Installation location is free from freezing.
Means maintenance space.
