Hisense AHM-080FJFAA - Install Electric Three-Way Valve

WL
Tco
HL
L1 N1
WN
HN
L1 N1 HL HN Tco
WL
WN
LN
1 5
1AB
2
56
44
10.2.5 Connect Communication Cable
outdoor unit
communication
wired
controller
external
input
In-site wire
Off-site wire
In-site
wire
Off-site wire
Shielding Signal Line
Wiring Harness
Fix Shielding Signal
Line with B ands
ʽ
CAUTION
Communication cable between outdoor unit
and water module is fixed with wiring harness.
10.2.6 Connect P ower Line
(1) Connect power line and earth wire to the
terminal of electric box and fix with wiring
harness, seen below.
(2) Check and ensure live line and null line of
terminal blocks in power supply are correctly
linked. If connected inversely, some parts may
be damaged.
water module
electric heating
water tank
electric heating
power line
11. Install Electric Three-way Valve
Electrical three-way valve is used only when
domestic water tank and cooling fan coil are
mounted.
11.1 Valve B ody Confirmation
The installation method of electrical three-way valve
and connection direction of water pipe are exclusive.
Ensure the arrow on valve rod aligns with black circle
before installation.
11.2 Install Actuator
Tighten coil and valve body. Three-core line of
actuator must be opposite to lateral outlet of
three-way ball valve.
11.3 Connection D irection of Water Pipe
●
Flow direction identifications are provided on
valve body. Link water module outlet pipe to
“water inlet”, floor heating to “water outlet 1” and
domestic water tank or cooling fan coil to “water
outlet 2”.
Communication Cable
