Suspension
Front Independent, Dual A-arm type
Rear Independent, Dual A-arm type
Max. rolling weight (Towing Capacity) kg (lbs.)
544（1200）
Payload capacity kg (lbs.)
159（350）
Weight kg (lbs.)
590（1301）for HS500UTV-5
590（1301）for HS550UTV
621（1369）for HS600UTV-3
621（1369）for HS700UTV-7
710（1565）for HS750UTV
Cargo bed
Width mm (in.) 1170(46.06)
Length mm (in.)
900（35.43）
Depth mm (in.)
280（11）
Volume m
3
(cu.ft.)
0.29（10.24）
Bed height
(unloaded)
mm (in.) 810（31.89）
Cargo bed capacity
(1 row/2 row)
kg (lbs.) 159（350）
Sound level, operator ear db (A)
86.5
Tire
Front
25×8-12/12×6 (min); 27×9-14/14×7(max) 6PR
Rear
25×10-12/12×8(min); 27×11-14/14× 9(max) 6PR
Body color Red, Black, White, Blue, Yellow, Orange, Camo
NOTE:
The values in “Ground clearance” and “Weight” are those of the machine equipped with the tir
es
i
n the table above.
The company reserves the right to change the specifications without not
ice.
